塑殼配電保護CDM6I-400L/3300 250A
產品概述
德力西CDM6i-400L/3300塑殼斷路器是一款專為配電網絡保護設計的電氣設備，適用于交流50Hz、額定工作電壓至400V的電路系統。該產品采用熱磁脫扣技術，具備過載和短路雙重保護功能，額定電流250A，殼架電流400A，分?jǐn)嗄芰_(dá)50kA，能有效保障線路和電源設備的安全運行。其緊湊的模塊化設計便于安裝維護，三極結構配合板前接線方式，可廣泛應用于工業控制、電動機保護及家居配電等場景。27
核心功能特點
本產品通過精確的熱磁脫扣單元實現反時限過載保護和瞬時短路保護，脫扣電流值可調以適應不同負載需求。采用壓磁式脫扣機構，響應速度快且穩定性高，機械壽命達1000萬次以上。透明外殼設計便于觀察內部狀態，手柄直接操作方式簡化了控制流程。支持垂直或水平安裝，板后接線結構節省空間，適用于密集型配電柜布局。特殊滅弧技術可快速切斷故障電流，減少電弧對設備的損傷。311
技術參數說明
CDM6i-400L/3300的額定絕緣電壓為400V，額定工作電流250A（可調范圍100A-400A），極數3P無N極配置。外形尺寸為75×120×60mm，重量約1.2kg，工作環境溫度范圍-5℃至+40℃。產品采用無附件標準配置，可選配分勵脫扣、輔助觸點等模塊化附件。熱脫扣特性符合I類曲線，磁脫扣整定值為10-12倍額定電流，能有效區分啟動電流與故障電流。914
應用領域
該斷路器適用于配電系統中的主干線保護和支路保護，可防止因過載、短路引起的設備損壞。在工業自動化領域，能為電動機、變壓器等設備提供可靠保護；在建筑配電中，可用于樓層配電箱、母線槽等場景；還可應用于新能源發電、軌道交通等特殊環境。其選擇性保護特性可實現與下級斷路器的級聯配合，提高供電連續性。1013
Product Introduction
The DELIXI CDM6i-400L/3300 molded case circuit breaker is designed for power distribution network protection, suitable for 50Hz AC systems with rated operational voltage up to 400V. Featuring thermomagnetic trip technology, it provides both overload and short-circuit protection with 250A rated current and 400A frame size. The 50kA breaking capacity ensures reliable protection for electrical circuits and equipment. Its compact modular design simplifies installation in industrial control systems, motor protection circuits, and residential power distribution applications. 27
Key Features
This product utilizes precision thermomagnetic trip unit with adjustable settings for customized protection. The magnetic trip mechanism ensures fast response to short-circuit faults while thermal element handles overload conditions. Transparent cover allows visual status inspection, and direct handle operation enables manual control. With vertical/horizontal mounting flexibility and rear terminal connections, it optimizes space utilization in panel boards. Advanced arc quenching technology minimizes damage during fault interruption. 311
Technical Specifications
Rated insulation voltage: 400V; Rated operational current: 250A (adjustable 100A-400A); Poles: 3P without neutral. Dimensions: 75×120×60mm; Weight: approx. 1.2kg; Ambient temperature range: -5℃ to +40℃. Standard configuration excludes accessories, with optional shunt release and auxiliary contacts available. Thermal trip follows Class I curve, magnetic trip setting at 10-12×In for effective discrimination between startup currents and fault currents. 914
Application Scenarios
Ideal for main circuit and branch protection in power distribution systems to prevent equipment damage from overload/short-circuit. Widely used in industrial automation for motor and transformer protection, building power distribution for floor panels and busways, as well as specialized environments like renewable energy systems and rail transit. Selective coordination capability enables cascade protection with downstream breakers to enhance power supply continuity. 1013
