BC-8A聲光報警器
BC-8A聲光報警器產品介紹（中文）
BC-8A聲光報警器是一款專為工業環境設計的警示設備，采用鋁合金壓鑄外殼，結構輕巧且耐腐蝕，具有良好的防水防塵性能。其核心部件采用集成電路設計，工作穩定性強，抗干擾能力突出。閃光燈部分選用高亮度LED燈管，發光效率高且使用壽命長，燈罩采用PC材料，透光性和抗沖擊性能良好。該產品適用于起重機械、港口設備、冶金、礦山、船舶等多種工業場景，能有效提供聲光同步警示功能。工作電壓支持AC220V/AC380V等多種規格，并可根據需求定制特殊電壓。音調可選A/B/E/D/Y等多種模式，音量可調節，滿足不同環境的使用需求。安裝方式簡單，通過4個M8螺絲固定，適合戶外或復雜工況下的長期穩定運行。212223
BC-8A Sound & Light Alarm Product Introduction (English)
The BC-8A Sound & Light Alarm is an industrial-grade warning device featuring an aluminum alloy pressure-cast housing that combines lightweight construction with corrosion resistance and IP65-rated protection. Equipped with high-brightness LED flashing lights and a polycarbonate lens, it delivers excellent visibility and durability. The built-in integrated circuit ensures reliable operation with strong anti-interference capabilities. Suitable for cranes, port machinery, metallurgy, mining, and marine applications, this alarm offers synchronous audible and visual alerts. It supports multiple voltage options including AC220V/AC380V and provides adjustable volume with selectable tones (A/B/E/D/Y). The product can be securely mounted using four M8 screws, making it adaptable for outdoor or harsh environments. Its compact design and maintenance-free characteristics make it a practical solution for industrial safety signaling. 212325
產品特點補充說明
該報警器設計考慮了實際應用場景的需求，具有多種音效模式可選，包括蜂鳴、語音提示等，能適應不同噪聲環境下的警示要求。外殼采用流線型設計，不僅美觀大方，還能有效防止雨水和灰塵進入內部。工作溫度范圍覆蓋-30℃至+70℃，適合在極端氣候條件下使用。產品重量約3.3kg，便于安裝和運輸。222427
Additional Product Features
The alarm provides flexible installation options with vertical mounting capability for optimal sound projection. Its advanced acoustic design ensures clear warning signals even in noisy environments. The device operates reliably across a wide temperature range from -30℃ to +70℃, making it suitable for various climatic conditions. With an approximate weight of 3.3kg, it balances sturdiness and portability. The streamlined housing design not only enhances aesthetic appeal but also improves environmental resistance. Multiple control modes allow integration with different automation systems. 232528
BC-8A聲光報警器聲光報警器BC-8A
產品簡介：
大型起重機械等行走設備在冶金企業中是非常重要的設備，它露天作業使用頻繁、啟動聲音小、速度較快，容易因不被現場人員注意而發生**事故。我廠生產的TBJ-150一體化聲光報警器，是針對大型起重機械的工作特點和結構特性而開發的專用報警器，具有許多專業化的特點。
產品特點：
·5W、25W報警音響——聲音宏亮
·帶不銹鋼防護罩旋轉警燈——高亮度、耐沖擊
·防風雨電路工藝設計——防水、防塵、質量可靠
·警燈、警號一體化——安裝簡便
·交流220V觸發即報警——操作簡單
·可選擇高亮度LED頻閃燈——高質量、壽命長、高亮度
技術參數：
BC-8A
|
工作電壓
AC220V、50Hz
|
警號功率
5W、25W
|
警燈直徑
D=150mm
|
|
防護罩
不銹鋼
|
觸發信號
AC220V
|
殼體材料
鋼板、噴涂
|
|
外形尺寸（高x長x寬）：435x180x155（mm）
|
BC-8A
|
工作電壓
AC220V、50Hz
|
警號功率
5W、25W
|
警燈直徑
D=150mm
|
|
防護罩
不銹鋼
|
觸發信號
AC220V
|
殼體材料
鋼板、噴涂
|
|
外形尺寸（高x長x寬）：435x180x155（mm）
|
