塑殼斷路器CDM3-125T/3300 125A
產品概述
德力西塑殼斷路器CDM3-125T/3300 125A是一款三相配電保護設備，適用于交流額定電壓690V及以下的配電系統中。該產品采用熱磁式脫扣機構，具有過載和短路保護功能，能夠有效保護線路和用電設備安全。其殼架等級電流為125A，額定電流可調范圍為80A至125A，分?jǐn)嗄芰_(dá)到35kA。產品設計緊湊，采用固定式板前接線方式，安裝維護便捷。159
產品特點
CDM3-125T/3300塑殼斷路器采用工業級外觀設計，面蓋可拆卸結構便于附件安裝。產品工作溫度范圍寬泛，在-5℃至+40℃環境下均可穩定運行，適應不同氣候條件。斷路器操作機構采用手柄直接操作方式，具有明顯的分合閘位置指示。產品污染等級為3級，適用于一般工業環境。其精巧的體積設計節省了安裝空間，同時保證了可靠的電氣性能。816
技術參數
該斷路器極數為3P，額定絕緣電壓800V，最大工作溫度85℃。產品單位重量約2.0kg，采用盒裝包裝，最小起訂量為1臺。脫扣器類型為熱磁式，具有過載延時保護和短路瞬時保護功能。斷路器符合常規工業應用要求，適用于配電系統的主開關或分支保護。產品采用優質工程塑料外殼，具有良好的絕緣性能和機械強度。37
應用領域
CDM3-125T/3300塑殼斷路器廣泛應用于工業控制柜、配電箱、機械設備等場合。產品適用于常規負載的配電保護，包括電動機、變壓器等設備的線路保護。其穩定的性能表現使其成為工業自動化、建筑配電等領域的常用元件。斷路器可單獨使用或與其他電氣元件配合組成完整的配電系統。1421
Product Overview
The DELIXI CDM3-125T/3300 125A molded case circuit breaker is a three-phase distribution protection device designed for electrical systems with AC rated voltage up to 690V. Featuring thermal-magnetic trip mechanism, it provides reliable overload and short-circuit protection for circuits and connected equipment. With frame current rating of 125A and adjustable current setting from 80A to 125A, it offers breaking capacity of 35kA. The compact design incorporates fixed front terminal connection for easy installation and maintenance. 59
Key Features
This breaker adopts industrial-grade appearance design with removable cover for convenient accessory installation. It operates stably within wide temperature range from -5℃ to +40℃, suitable for various climate conditions. The visible toggle handle clearly indicates ON/OFF positions. Designed for pollution degree 3 environments, it meets general industrial application requirements. Its space-saving compact size doesn t compromise electrical performance. 816
Technical Specifications
The 3-pole breaker features rated insulation voltage of 800V and maximum operating temperature of 85℃. Each unit weighs approximately 2.0kg with box packaging, available in minimum order quantity of 1 piece. The thermal-magnetic trip unit provides both time-delay overload protection and instantaneous short-circuit protection. Made with high-quality engineering plastic housing, it ensures excellent insulation and mechanical durability. 37
Typical Applications
Widely used in industrial control panels, distribution boxes and machinery equipment, this breaker suits general load protection including motors and transformers. Its stable performance makes it popular in industrial automation and building electrical systems. It can work independently or coordinate with other components to form complete distribution solutions. 1421
