CDM3-250S/3320 200A塑殼斷路器產品介紹（中文）
CDM3-250S/3320 200A塑殼斷路器是針對現代配電系統設計的專業電氣保護設備，適用于交流50Hz/60Hz、額定工作電壓至690V的電力網絡。產品采用創新結構設計，具備優異的電氣性能與機械耐久性，可有效實現線路的過載、短路保護功能，為各類工業、商業及基礎設施的用電安全提供可靠保障。
本產品主體結構采用高強度工程材料模壓成型，殼體具備良好的絕緣性能和抗沖擊特性。核心觸頭系統運用特殊合金材料配合多層滅弧室設計，有效提升電弧分?jǐn)嗄芰Α?00A額定電流規格可滿足常規配電柜主回路及大容量分支回路的保護需求，操作機構采用彈簧儲能式設計，確保分合閘動作快速可靠。產品提供三極結構，緊湊式外形設計在保證安全間距的同時優化了安裝空間，支持垂直或水平多種安裝方式。
該斷路器配置可視化分合閘指示與機械自由脫扣機構，操作人員可通過外部手柄直觀掌握設備狀態。模塊化功能單元設計便于后期維護，支持多種附件擴展安裝。針對不同使用環境需求，產品內部組件經過特殊工藝處理，可在-35℃至+70℃環境溫度下穩定運行，適應潮濕、粉塵等復雜工況。
典型應用包括：工廠配電系統的主開關保護、商業建筑樓層配電箱、光伏發電系統直流側保護、港口機械動力控制柜等場景。通過科學的參數匹配，能有效協調上下游保護裝置的動作選擇性，最大限度降低故障停電范圍。產品設計注重用戶操作體驗，人性化的安裝卡扣和清晰的標識系統可顯著提升工程效率。
CDM3-250S/3320 200A Molded Case Circuit Breaker Product Introduction (English)
The CDM3-250S/3320 200A molded case circuit breaker is a professional electrical protection device developed for modern power distribution systems. Suitable for AC 50Hz/60Hz networks with rated operational voltage up to 690V, it delivers reliable overload and short-circuit protection for industrial, commercial, and infrastructure applications.
Featuring an innovative modular construction, the breaker s high-strength thermoplastic housing provides excellent dielectric strength and mechanical robustness. The multi-contact system with arc chute configuration ensures efficient arc extinguishing capability. With 200A current rating, this 3-pole device optimally protects main circuits and high-capacity branch lines in power distribution systems. The spring-operated mechanism guarantees swift and consistent switching operations, while compact dimensions allow flexible vertical/horizontal mounting in limited spaces.
Visual position indicators and manual operating handles enable clear status monitoring. The trip-free mechanism immediately interrupts fault currents regardless of handle position. Modular accessory slots support functional expansions such as shunt releases or auxiliary contacts. Internal components undergo specialized treatment to maintain stable performance within -35℃ to +70℃ ambient temperature range, demonstrating strong adaptability in humid or dusty environments.
Typical applications include: Main switchgear protection in factory substations, floor distribution cabinets in commercial buildings, DC-side protection for photovoltaic systems, and motor control centers in port machinery. The product s selective coordination capability helps minimize power outage scope during system faults. User-friendly features include tool-free installation clamps, color-coded terminals, and ergonomic handle design to streamline installation and maintenance processes.
Engineered for durability, the breaker s silver-alloy contacts and corrosion-resistant hardware ensure long service life. The balanced magnetic circuit design effectively reduces power loss during normal operation. This solution combines robust
