框架斷路器CDW1-2000 1250/1250 三極(固定式)AC380V
產品概述
德力西CDW1-2000系列框架斷路器是一款高性能配電保護設備，采用三極固定式設計，額定電流1250A，適用于交流380V電壓系統。該產品采用模塊化結構設計，核心部件包括智能控制器、觸頭系統、滅弧室及操作機構，能夠實現電能分配和線路保護功能。產品外殼采用高強度金屬框架，內部布局緊湊合理，具有分斷能力高、操作穩定可靠的特點。16
技術特點
該斷路器配備智能電子脫扣系統，可精準監測過載、短路等異常電流，并具備三段保護功能（瞬時、短延時、長延時）。觸頭系統采用銀合金材料，配合多重滅弧柵設計，有效抑制電弧產生。操作機構采用彈簧儲能式設計，支持手動和電動兩種操作方式，機械壽命達10,000次以上。產品支持水平或垂直安裝方式，主回路接線端子采用母排直連結構，接觸電阻低且散熱性能優異。369
應用場景
主要應用于工業配電系統的主干線保護和電動機保護，適用于發電廠、變電站、工礦企業等場合。在正常工況下可實現線路不頻繁切換，特別適合1250A以下電動機的啟動保護。產品防護等級達到IP30，可在-5℃至+40℃環境溫度下穩定運行，適應相對濕度90%以下的工況條件。抽屜式設計版本還可實現快速檢修更換，減少系統停機時間。4713
Product Introduction
The DELIXI CDW1-2000 frame circuit breaker is a high-performance power distribution protection device with 3-pole fixed type design, rated current 1250A and suitable for 380V AC systems. Featuring modular structure, its core components include intelligent controller, contact system, arc extinguishing chamber and operating mechanism, which provide reliable power distribution and circuit protection functions. The robust metal frame housing ensures structural integrity while compact internal layout optimizes performance. 15
Technical Features
Equipped with smart electronic trip system, this breaker precisely monitors abnormal currents including overload and short circuit, providing three-stage protection (instantaneous, short-time delay, long-time delay). The silver-alloy contacts combined with multi-grid arc chute effectively suppress arc generation. Spring-energy storage mechanism supports both manual and electric operation modes with mechanical durability exceeding 10,000 cycles. Horizontal or vertical installation options are available, and the main circuit terminals adopt busbar direct-connection structure for low contact resistance and excellent heat dissipation. 3616
Application Fields
Primarily used for main circuit protection and motor protection in industrial power systems, suitable for power plants, substations and manufacturing facilities. Under normal conditions, it enables infrequent circuit switching and is particularly effective for motor starting protection below 1250A. With IP30 protection grade, the product operates stably within ambient temperatures from -5℃ to +40℃ and relative humidity up to 90%. The withdrawable version facilitates quick maintenance and replacement to minimize system downtime. 41317
框架斷路器CDW1-2000 1250/1250 三極(固定式)AC380V
