BC-2H聲光報警器
BC-2H聲光報警器產品概述
BC-2H聲光報警器是一款專為港口起重機械、冶金及機電行業設計的多功能安全警示設備，適用于行車、門吊等大型設備的司機室內。該產品采用鋁合金外殼，結構輕巧且耐腐蝕，兼具防水防塵性能，能在-20℃至+70℃環境下穩定工作。其核心功能包括高音量報警（106dB-110dB）、多音調選擇（如A/B/E調或定制語音），并支持手持話筒喊話與聲光同步報警，有效協調作業安全。內置25W-100W大功率揚聲器，音量可調，適用于嘈雜工業環境。1215
Product Introduction of BC-2H Audio-Visual Alarm
The BC-2H audio-visual alarm is a compact and durable safety device designed for port cranes, metallurgy, and large-scale machinery. Its aluminum alloy housing ensures resistance to corrosion and environmental factors, with an operational temperature range of -20℃ to +70℃. The alarm features a high-decibel output (106dB-110dB), adjustable volume, and multiple tone options (e.g., A/B/E or customized voice prompts). Integrated with a handheld microphone for broadcasting, it supports simultaneous audio and visual alerts (optional strobe light), enhancing safety coordination in industrial settings. The built-in 25W-100W speaker adapts to noisy environments. 2224
功能特點與適用場景
BC-2H支持延時報警（5-20秒可調）和靈活配置，如外接鵝頸話筒或遠程開關控制。其示警燈采用高亮LED，壽命超10萬小時，配合PC燈罩抗沖擊性強。典型應用包括冶金車間、礦山設備及港口機械，通過聲光提示預防人身傷害和設備事故。產品安裝簡便，通過M5螺絲固定，需注意電源電壓匹配（支持AC24V-380V/DC24V）和避免短路。82126
Key Features & Applications
The BC-2H offers delay alert customization (5-20s adjustable) and modular configurations, such as goose-neck microphones or remote switches. Its LED strobe light (100,000-hour lifespan) and polycarbonate cover ensure durability. Ideal for heavy industries like metallurgy and mining, the alarm mitigates operational risks through clear audiovisual warnings. Installation requires M5 screws and voltage compatibility checks (AC24V-380V/DC24V). Note: Control units are recommended for indoor use only. 182327
設計優勢與用戶體驗
產品設計注重實用性與美觀，冷軋鋼板控制箱僅重3kg，接線端子靈活（插座式或端子式可選）。用戶可依據需求選擇音調組合或語音內容，如工程車聲、警鈴聲等。實際使用反饋表明，其多種音調提示顯著提升了作業協調效率與安全性。152226
Design Advantages & User Experience
With a 3kg cold-rolled steel control box and versatile wiring options (socket or terminal), the BC-2H balances functionality and aesthetics. Users can select preset tones (e.g., sirens, machinery sounds) or upload custom audio. Field tests confirm its effectiveness in enhancing on-site safety and operational coordination. 2428
BC-2H聲光報警器
|
接線方法
|
|
|
|
電源線 引入口(CABLE ENTRY)
|
|
|
|
|
|
1.使用防水接頭或者船舶用填料函
|
|
|
2.電源線 接入口:標準規格 : PF 1/2
|
|
|
3.引入口 PF 3/4 尺寸可以定做
|
|
|
接線方法
|
|
|
1.AC交流電源產品：不用分正負極,直接連接電源.
|
|
|
2.DC直流電源產品：黑色線端子連接在負極(-)。
|
|
|
3.為了更**的連接,電源線的端部使用冷壓接線端子“O"型"U"型
|
|
|
|
